Cylinder 2 Stroke Petrol Engine Test Rig

Next > >

Send Inquiry

Product Code : AE-001

Product Description

Advanced Technocracy Inc. is Manufacturer, Exporter & Supplier of Cylinder 2 Stroke Petrol Engine Test Rig

The setup consists of single cylinder, two stroke, petrol engine connected to rope brake / Electric type dynamometer for variable loading. The setup has stand-alone type independent panel box consisting of air box, fuel tank, and manometer, fuel measuring unit.

Experiments

Study of engine performance for power, efficiencies, fuel consumption, air fuel ratio

Utilities Required

Electric supply: Provide 230 +/- 10 VAC, 50 Hz, single phase electric supply with proper earthing. (Neutral – Earth voltage less than 5 VAC)
Space: 3300Lx2900Wx1700H in mm
Fuel, oil: Petrol: Oil mixed petrol (2T oil, 30 – 50 ml/lit) @ 10 liter. Lubricating oil: @ 0.5 liter (20W40)
