Stability Chamber

Stability Chamber
Stability Chamber
Product Code : AM-10209
Product Description

Stability Chamber

Advanced Technocracy Inc. is Manufacturer, Exporter & Supplier of Stability Chamber .
ATICO Super Deluxe automatic, Temperature is controlled by electronic digital temperature controller cum indicator. Temp. Range from 5°C-50°C with the sensitivity of ±1°C. Inside air circulating system has FH motor and fan which keeps uniform temperature throughout the chamber. Double walled inside outer cabinet is made of M.S. Sheet coated with epoxy powder paint; inner chamber is made of highly polished stainless steel. 2 Doors, outer door is insulated and is fitted with magnetic gasket for air tight closing for no temperature loss. Inner door is made of transparent acrylic glass empanelled in aluminum door frame. Electronic digital read out timer and interior illumination with 3 nos. Fluorescent tube, separate On/Off switch for tubes and minimum temperature can be obtained from 10°C-50°C when all the tubes are on. Humidity control from 55%-95% by humidistat.

SALIENT FEATURES & CONSTRUCTION

  • Robust construction outer chamber is made of Mild Steel duly pre treated & finished with powder coated paint for lasting finish.

  • Inner chamber made of ST AINLESS STEEL SHEET (304 Grade).

  • Fitted with durable coaxial blower for forced air circulation at triple walled back to maintain temperature uniformity in the chamber.

  • Outer front double walled door is insulated and is fitted with magnetic tape for air tight closing for no temperature loss, provided with lock and key arrangement.

  • Inner chamber has SS angels for placing the shelves at convenient levels. Supplied with 2 or 3 removable shelves.

  • A full view inner plexi-glass door enables inspection and monitoring of inner chamber specimens without disturbing the process temperature.

  • High grade PUF INSULA TION between outer and inner chamber for minimal thermal losses.

  • Cooling is done by finned tube evaporator lie in the air circulation path by ISI marked Compressor/Condensing Units CFC free & R-134 a eco friendly refrigerant.

  • Heating is done by indirect heating system by air heaters made of stainless steel placed in the path of moving air in the chamber.

  • Temperature Range. Temperature ranges of our Stability Chamber models are 200C to 600C.

  • Temperature controlled by microprocessor based temperature controller having LED display with an accuracy of +10C fitted with PT-100 sensor (Resolution 0.10C)

  • Humidity System: Humidity is generated by steam injection system consist of boiler tank, placed below the chamber fitted with boiler heater.

  • Humidity Range: 50% of 90% & controlled by mean of an electronic humidity controller cum indicator with an accuracy of + 3 to 5%RH.

  • LAPBRO Control panel having all controls and circuitry are housed at the top fitted with Temperature controller cum Indicator Microprocessor based with LED display for Set Value (SV) & Process Value (PV) to select any desired temperature & humidity controller cum indicator provided with Volt meter on the panel to read the incoming voltage.

  • Caster wheel mounted for easy portability .

  • Supplied with cord and plug.

  • Operating Voltage: 220 Volts AC (50 Hz).
