Universal IC Tester

Universal IC Tester
Universal IC Tester
Product Code : IC-001
Product Description

 Universal IC Tester

Advanced Technocracy Inc. is Manufacturer, Exporter & Supplier of  Universal IC Tester

We are an eminent name, which is engaged in offering an unmatched range of Universal IC Tester. The offered range of universal IC tester is available in different customized specifications and forms in accordance with the diverse requirements of respectable clients. Along with this, the offered range of universal IC tester is suitably inspected on different characteristics to maintain its authenticity throughout the designing process.



One system has many functions:

  • IC tester
  • Word processor
  • MC development system
  • Simple cable tester
  • Beside testing gates, buffers and decoder ICs in-circuit, this range is available with which the IC could be tested without removing from board. In in-circuit mode, six logic inputs could be driven and three logic outputs could be monitored. Along with this, the offered range is known for checking analog / linear ICs including microprocessor, micro controllers, EPROMs, peripheral devices apart from 74 series of TTL ICs and 40/45 series of CMOS IC's.

Features:

  • No personality cards / reference IC / IC Data required
  • ONE mode to test IC once
  • CON mode to test IC continuously
  • STEP mode to test step by step
  • Buzzer to indicate bad ICs
  • Reliable PC keyboard to enter IC number and commands
  • Potential free 40 pin ZIF socket for easy insertion of IC under test
  • Protection against wrong insertion
  • Simple cable tester with learn facility
  • Alphanumeric 40 x 2 back lite LCD for displaying messages
  • RS 232 serial interface expansion of IC test library
  • Built in self test to test hardware, display, keyboard and buzzer
  • Built in word processor mode which converts system into an electronic typewrite
  • Indigenously developed universal pin driver technology used
  • Help message through F1 key

Working:

  • It has facility for expansion of test library through RS232C serial interface
  • If the data sheets of the new IC is furnished along with sample ICs, we could develop the testing program if the IC is testable
  • After downloading this test program in the tester, the new IC could be tested



Technical specifications:

  • Test range digital analog/linear ICs 6, 8, 14, 18, 20, 24, 28 & 40 Pin in dual in line (DIP) package
  • Socket 40 pin universal type ZIF (zero insertion force)
  • Display 40 x 2 back-lite alphanumeric LCD display
  • Keyboard external IBM-PC PS/2 keyboard
  • Voltage 230 V, AC 50 Hz ± 10%
  • Enclosure sheet metal cabinet with powder coating and engraving
  • Dimensions 34 x 31 x 9 cm
  • Weight 5.5 Kg approximately
